Three Phase 10.5 to 15 kva
Description
| Engine | |
| Cooling | Air (Radial) |
| No. of Cyl. | One / Two |
| Fuel | H.S. Diesel |
| Type | Vertical ,4-stroke,compression ignition |
| Speed | 1500 RPM |
| Starting | Handle start (Optional-Electrical) |
| Fuel tank | 10 to 20 liters |
| A. C. Generator | |
| Voltage | 415 V |
| Phase | Three |
| Frequency | 50 Hz |
| Regulation | ± 5 % Max. |
| Insulation | F Class |
| Technical Specification | |||||||
| AC Generators (Alternator) | Diesel Engine | ||||||
| Model | Rated Power | No. of Phase | Current (Amps) | Power Factor | Rated Power (HP) | Dry Weight (Kg) | |
| KVA | KW | ||||||
| PAT 1050* | 10.5 | 8.4 | THREE | 14.0 | 0.8 (LAG) | 14.0 | 365 |
| PAT 1250 * | 12.5 | 10.0 | THREE | 17.0 | 0.8 (LAG) | 16.0 | 473 |
| PAT 1500 * | 15.0 | 12.0 | THREE | 20.0 | 0.8 (LAG) | 20.0 | 490 |
