Single Phase 2.5 to 7.5 kva

Description

Engine
Cooling Air (Radial)
No. of Cyl. One
Fuel H.S. Diesel
Type Vertical ,4-stroke,compression ignition
Speed 1500 RPM/1800 RPM
Starting Handle start (Optional-Electrical)
Fuel tank 5 to 10 liters
A. C. Generator
Voltage 230/415 V
Phase Single
Frequency 50 Hz
Regulation ± 5 % Max.
Insulation F Class
Technical Specification
AC Generators (Alternator)Diesel Engine
ModelRated PowerNo. of PhaseVoltsCurrent (Amps)Power FactorRated Power (HP)Dry Weight (Kg)
 KVAKW
PAS 250*2.52.5ONE23010.01.0 (UPF)4.0145
PAS 300 *3.03.0ONE23012.01.0 (UPF)4.5160
PAS 400 *4.04.0ONE23017.41.0 (UPF)7.0275
PAS 500 *5.05.0ONE23020.01.0 (UPF)8.0295
PAS 600 *6.06.0ONE23024.01.0 (UPF)10.0305
