| Technical Specification |
| Model |
|
PWD – 350 |
PWD – 380 |
PAD – 350 |
| Electrical |
|
|
|
|
| Welding Current Range |
A |
50 – 350 |
50 – 380 |
50 – 350 |
| Max Hand Weld . Current @ 60% Duty Cycle |
A |
350 |
380 |
350 |
| Max Continous Hand Weld. Current @ 100% Duty Cycle |
A |
280 |
300 |
280 |
| Open Circuit Voltage (Max) |
Volts |
90 / 95 |
| Diameter of Electrode |
mm |
2 – 6.3 |
| As per specification |
BIS |
IS : 2635 |
| Degree of Protection |
BIS |
IP 23 of IS : 2147 |
| Mechanical |
|
|
|
|
| Engine Rating |
BHP |
20 |
25 |
20 |
| Cooling |
|
Water Cool |
Water Cool |
Air Cool |
| RPM |
RPM |
1500 |
1500 |
1500 |
| No of Cylinders |
Nos |
2 |
2 |
2 |
| Bore Size |
mm |
95 |
102 |
102 |
| Stroke |
mm |
110 |
115 |
110 |
| Fuel Consumption |
g / bhp-h |
175 |
175 |
188 |
| Auxiliary Power |
|
|
|
|
| Type |
|
A.C. |
| Rating |
KVA |
4.5 |
| Voltage |
Volts |
220 |
| Hz |
Hz |
50 |
| General |
|
|
|
|
| Fuel Tank Capacity |
Ltrs |
20 |
| Dimension of the Set ( Length * Width *Height) |
mm |
1580 * 610 * 1170 |
1780 *610 *1200 |
1580 * 610 *1060 |
| Net Weight (approx.) |
Kg |
585 |
610 |
560 |
