| Technical Specification |
|
|
|
|
|
|
| S.No. |
Silent Genset model |
Genset Capacity (KVA/KW) |
Cooling |
Engine Model(ICAT) |
ICAT-Certificate No |
ARAI- certificate No. |
| 1 |
PSG 500S |
5 KVA |
WATER |
PV-12
(Single Cylinder) |
ICAT/MOEF/DGTA/PRAKASH DIESELS-F5/J-0629 DT: 18-07-2014 |
ARAI/DGTA/PDPL/PSG750T/2014/5203, DT: 19-01-2015 |
| 2 |
PSG 500S |
6 KVA |
WATER |
| 3 |
PSG 625 T |
6.25 KVA |
WATER |
| 4 |
PSG 750 G |
7.5 KVA 1Ø |
WATER |
| 5 |
PSG 750 T |
7.5 KVA 3Ø |
WATER |
|
|
|
|
|
|
|
| 1 |
PSG 1000 |
10 KVA |
WATER |
PV-20
(Double Cylinder) |
ICAT/MOEF/DGTA/PRAKASH DIESELS-F5/J-0629 DT: 18-07-2014 |
ARAI/DGTA/PDPL/PSG 1500/2014/5204, DT: 19-01-2015 |
| 2 |
PSG 1200 |
12 KVA |
WATER |
| 3 |
PSG 1250 |
12.5 KVA |
WATER |
| 4 |
PSG 1400 |
14 KVA |
WATER |
| 5 |
PSG 1500 |
15 KVA |
WATER |
|
|
|
|
|
|
|
| 1 |
PASG 300 |
3 KVA |
AIR |
EPA-10
(Single Cylinder) |
ICAT/MOEF/DGTA/PRAKASH DIESELS-F14/J-1029 DT: 30-12-2014 |
ARAI/DGTA/PDPL/PASG 400/2015/5434, DT: 11-11-2015
ARAI/DGTA/PDPL/PASG 750/2015/5259, DT: 27-02-2015 |
| 2 |
PASG 350 |
3.5 KVA |
AIR |
| 3 |
PASG 400 |
4 KVA |
AIR |
| 4 |
PASG 500 |
5 KVA |
AIR |
| 5 |
PASG 750 |
7.5 KVA |
AIR |
|
|
|
|
|
|
|
| 1 |
PASG 1000 |
10 KVA |
AIR |
EPA-20
(Single Cylinder) |
ICAT/MOEF/DGTA/PRAKASH DIESELS-F4/J-1049 DT: 30-12-2014 |
ARAI/DGTA/PDPL/PASG 1500/2015/5260, DT: 27-02-2015 |
| 2 |
PASG 1250 |
12.5 KVA |
AIR |
| 3 |
PASG 1500 |
15 KVA |
AIR |
