Self Priming Pump

Description

Eco-Prime

Features

  • Can withstand wide voltage fluctuation from 180 to 240 Volts
  • Self  priming up to 7.5 meters
  • Thermal Overload Protector (TOP) prevents motor burning out
  • Stainless steel shaft to avoid rust problem
  • Locked Impeller results in consistent performance
  • Aluminum extruded motor body for better heat dissipation and corrosion resistance
  • TEFC’ capacitor start and run motor with IP-44 protection and class ‘B’ insulation
  • Double shielded ball bearings – no need for external lubrication
  • Capacitor inside terminal box

Material of construction

Impeller                                :         Forged Brass

Delivery Casing                   :        Cast Iron

Motor Body                          :        Aluminium

Mounting Casing                :        Cast Iron

Shaft                                     :        Stainless Steel



Applications

  • Water supply for  bungalows, apartments, hotels,  hospitals, farmhouses etc.
  • Useful in home pressure booster systems, lawn sprinklers, overhead tanks and watering gardens.

Technical Specifications

Head                               :        6 to 24 meters

Capacity                         :        2250 to 400 LPH

Power Rating                 :        0.37 kW (0.5 Hp)

Voltage Range                 :         180 to 240 Volts

Maxi Flow II

Features

  • Motor can withstand wide voltage fluctuations from 180 to 240 Volts
  • Sell priming up to 7.5 meters
  • Fitted with thermal overload protector (TOP) to Prevent motor burning out in cases of high voltage drop
  • Totally enclosed Fan Cooled (TEFC) motor
  • Capacitor start and run motor with IP-44 protection
  • Class B insulation
  • Capacitor inside terminal box
  • Double shielded boll bearing needing no external lubrication

Material of construction

Impeller                                :        Brass HTB2

Delivery Casing                   :        Cast Iron

Motor Body                          :        0.5 HP – Aluminium Die Cast

                                               :        1.0 HP – Aluminium Extruded Die Cast

Shaft                                     :        Stainless Steel (EN8)



Applications

  •  Bungalows
  •  Hospitals
  • Garages
  •  Industries
  • Small fountains
  • Solar heating systems

Technical Specifications

Head Range                   :        6 to 40 meters

Discharge Range           :        3200 to 750 LPH

Power Rating                 :        0.37 and 0.75 kW / 0.5 and 1.0 HP

Voltage Range                 :         180 to 240 Volts

Super Flow

Features

  • Can withstand wide voltage fluctuation from 180 to 240 Volts
  • Self  priming up to 7.5 meters
  • Thermal Overload Protector (TOP) prevents motor burning out
  • High quality aluminium extruded motor body with chrome plated shaft
  • TEFC capacitor start and run motor with IP-44 protection and class ‘B’ insulation
  • Double shielded ball bearings – no need f or external lubrication
  • Light weight pump for easy handling
  • Easy maintenance and spares availability

Material of construction

Impeller                                :         Forged Brass

Delivery Casing                   :        Cast Iron

Motor Body                          :        Aluminium

Mounting Casing                :        Cast Iron

Shaft                                     :        Carbon Steel



Applications

  • Water supply for  bungalows, apartments, hotels,  hospitals, farmhouses etc.
  • Useful in home pressure booster systems, lawn sprinklers, overhead tanks and watering gardens.
  • Circulation of water in industries

Technical Specifications

Head Range                   :        6 to 24 meters

Discharge Range           :        2700 to 600 LPH

Power Rating                 :        0.37 kW (0.5 HP)

Voltage Range                 :         180 to 240 Volts

Suprime - Eco

Features

  • Can withstand wide voltage fluctuation from 180 to 240 Volts
  • Self-priming up to 7.5 meters
  • Thermal Overload Protector (TOP) prevents motor burning out
  • Total head-40 meters
  • Chrome plated shaft to avoid rust problem
  • motor with IP-44 protection and class ‘B’ insulation
  • shielded ball bearings – no need f or external lubrication
  • Light weight pump for easy handling
  • Available in single and three phase options

Material of construction

Impeller                                :         H.T.  Brass

Delivery Casing                   :        Cast Iron

Motor Body                          :        Aluminium

Shaft                                     :        Carbon Steel ( Chrome Plated)



Applications

  • Water supply for  bungalows, apartments, hotels,  hospitals, farmhouses etc.
  • Useful in home pressure booster systems, lawn sprinklers, overhead tanks and watering gardens.

Technical Specifications

Head Range                   :        6 to 40 meters

Discharge Range           :        3200 to 750 LPH

Power Rating                 :        0.37 and 0.75 kW / 0.5 and 1.0 HP

Voltage Range                 :         180 to 240 Volts- Single Phase

Suprime HD

Features

  • Can withstand wide voltage fluctuation from 180 to 240 Volts
  • High suction lift up to 7.5 meters
  • Designed for better performance in domestic applications
  • Thermal Overload Protector (TOP) prevents motor burning out
  • High quality aluminium extruded motor body with chrome plated shaft
  • TEFC capacitor start and run motor with IP-44 protection and class ‘B’ insulation
  • Capacitor inside terminal box

Material of construction

Impeller                                :         Brass

Pump Shaft                         :         Carbon – Steel ( Chrome plated )

Delivery Casing                   :        Cast Iron

Mounting Casing                :        Cast Iron

Motor Body                          :        Aluminium

Cover NDE                           :        Cast Iron

Mechanical Seal                 :        Carbon Ceramic



Applications

  • Water supply for domestic use in bungalows, apartments, hotels,  hospitals, farmhouses etc.
  • Useful in home pressure booster systems, lawn sprinklers, overhead tanks and watering gardens.
  • Circulation of water in industries

Technical Specifications

Head Range                   :        10 to 52 meters

Discharge Range           :        3960 to 360 LPH

Power Rating                 :        1.1 kW (1.5 HP)

Voltage Range                 :         180 to 240 Volts – single phase

Super Suchon

Features

  • Can withstand wide voltage fluctuation from 180 to 240 Volts
  • Self priming suction lift up to 7.5 meters
  • Thermal Overload Protector (TOP) prevents motor burning out
  • High quality aluminium extruded motor body with chrome plated shaft
  • TEFC capacitor start and run motor with IP-44 protection and class ‘B’ insulation
  • Shielded ball bearings – no need for external lubrication
  • Lightweight pump for easy handling

Material of construction

Impeller                                :         H.T.  Brass

Delivery Casing                   :        SS

Motor Body                          :        Aluminium

Shaft                                     :        Chrome Plated shaft



Applications

  • Water supply for domestic use in bungalows, apartments, hotels,  hospitals, farmhouses etc.
  • Useful in home pressure booster systems, lawn sprinklers, overhead tanks and watering gardens.
  • Circulation of water in industries

Technical Specifications

Head Range                   :        5 to 44 meters

Discharge Range           :        3400 to 400 LPH

Power Rating                 :        0.18 to 0.75 kW

Voltage Range                 :         180 to 240 Volts – single phase

HD - 10

Features

  • Can withstand wide voltage fluctuation from 180 to 240 Volts
  • Self priming suction lift up to 7.5 meters
  • TEFC capacitor start and run motor with IP-44 protection and class ‘B’ insulation
  • Double Shielded ball bearings – no need for external lubrication
  • Robust construction and reduced noise level
  • Bronze impeller locked on shaft
  • CED coated wetted components for long life and rust free operation . Better preventing against rust
  • More hygienic and potable for drinking water

Material of construction

Impeller                                :         Bronze

Delivery Casing                   :         Cast Iron

Motor Body                          :        Cast Iron

Shaft                                     :        Carbon Steel



Applications

  • Water supply for domestic use in bungalows, apartments, hotels,  hospitals, farmhouses etc.
  • Useful in home pressure booster systems, lawn sprinklers, overhead tanks and watering gardens.
  • Circulation of water in industries.
  • Curing with clear water at construction sites

Technical Specifications

Head Range                   :        8 to 46 meters

Discharge Range           :        3540 to 690 LPH

Power Rating                 :        0.37 to 0.75 kW ( 0.5 to 1.0 HP)

Voltage Range                 :         180 to 240 Volts – single phase
